Jot - Just and Only Text

What it is

Jot is a (mostly) mark-up free markup language.

Jot files can have no markup codes, and be as easy to read as plain text, yet be converted to styled XML or HTML

It achieves this by using white-space as a marker. Whitespace is skipped over by the eye and is non-distracting, unlike markup codes.

A Jot document uses indentation to show the structure, this scheme is sometimes naturally used to show the structure of text, as below:

Jot uses the concept of a 'default' tag for each child node, which avoids most markup (e.g. the top level node is the document title). However other tags can be specified with a simple syntax.

What it's for

Jot's hierarchical structure means editors can be used as single page outliners (if they are configured to 'fold' sections based on indentation level).

Jot files work with an arbitrary schema, so it is a compressed form of XML, while Markdown etc. are abbreviated syntaxes for HTML.

The process for converting jot to an arbitrary output starts with the app Jot2xml which converts jot format to XML, the XML file is then processed using XSL. This gives a lot of flexibility - any output that can be produced by XSL can be produced with jot.

Jot can also be used as a templating system, by using multiple XSL files or XSL parameters.

Some of the things that can be done with jot+XSL include:

produce arbitrary XML (e.g. open document format)
produce plain text output
make HTML
make different formats from one file, e.g. ODF and HTML.
variant files (i.e. generating one HTML document for the web and one for an intranet with different text in one place only)
produce sets of similar files from a template and source files containing unique text, i.e. like a text macro system

Comparison with markdown

Compared to Markdown, jot is:

harder to use you need a two stage process to make HTML from a jot file, vs one for Markdown
harder to extend Markdown allows embedded arbitrary HTML. In jot to add a new tag type you have to update the schema and the XSL
more powerful e.g. you can create HTML files with an arbitrary template in jot. For Markdown you would have to use an additional text macro system.
more flexible a jot file can be converted to multiple outputs, e.g. Markdown, reStructuredText, json (you need to write XSL files to do these)
stricter jot enforces a schema when it is converted to XML, meaning errors are caught immediately

How to use it

To create an HTML file from a jot file, first convert the jot file to XML by using the program jot2xml. Next convert that to HTML by using the file jotxml2html.xsl.

This XSL file is designed to work with the default (built-in) schema.

To customise the output, modify the XSL file.

Getting Started

Download the jot2xml executable (available for Windows and Linux).
Install an XSL processor.

For Windows I recommend saxonica.
For Ubuntu Linux you can run sudo apt install libsaxonb-java.
The XSL processor should support XSLT 2.0

Configure your text editor
Instructions for Vim, and Jedit are given in Editor settings.

For other editors, it must:
- NOT silently replace tabs with spaces.
- use soft-wrapping only, i.e. does not insert line feeds
- save in ASCII or UTF-8
Ideally it should also:
- indent wrapped lines at the start-of-line indentation level
- support 'folding' based on indentation level
- make spaces visible at the start of lines
- highlight jot syntax
- have other outliner features, such as 'hoisting'
Convert your jot file to HTML
There are sample bash and .bat files to do this named convert-jot-to-html.bat and convert-jot-to-html.sh. You will need to update the paths in these files.

Writing JOT files (syntax)

Indentation

A jot file distinguishes separate types of text - shown with different tags in HTML - by the indentation level. Each line is indented by tabs, and this shows the structure of the document.

For example if the first line is not indented this is the title of the page. Any line indented by one tab are headings. text indented by three tabs is body text and anything indented further is shown in a smaller font.

This is a simple HTML page:

This is the page title
	this is tagged as <H1>
		this is tagged as <h2>
			this is tagged with <p>, it's normal body text
			another paragraph of body text
				this is shown in a smaller font still
		another <H2> heading

Which tag represents each level is specified in the 'schema', but can be overridden by using markup in the jot file.

Each paragraph ends up as a node in the xml output, surrounded by <p>.

Markup

Sometimes you want a different tag than the default, this is done using markup.

Pipe tags

To markup a block of text as being a tag, you can use the tag name followed by the pipe symbol '|', on a line of it's own.

The tag 'ul' represents an unnumbered list, so to show a list of items like this;

ul|
	a
	b
	c
some more text

this is rendered as:

<ul>
	<li>a</li>
	<li>b</li>
	<li>c</li>
</ul>
<p>some more text</p>

note that the ul tag applies to the whole indented block, and that the default child tag for ul is li so there is no need for other markup.

More pipes

To tag a single line you can use a different syntax, that looks like

tag|line

. For example:

em|some text to emphasise
some more text

this will render as:

<em>some text to emphasise</em><p>some more text</p>

whitespace after a pipe symbol is ignored

Inline tags

If you don't want to make a separate line for a node, you can embed it in a line by using square brackets like this

first [em|text to emphasise] after

This is converted to:

first <em>text to emphasise</em> after

Attributes

A simpler way of adding a small subnode is the attribute style, like this

em class=my-class id=my-id|text to emphasise with class

This renders as:

<em class="my-class" id="my-id">text to emphasise with class</em>

Attributes are not a different type of node, just a different syntax. The above HTML will also be created by the following

					em|[class|my-class][id|my-id]text to emphasise with class

and

em|
	class|my-class
	id|my-id
	text to emphasise with class

sometimes you want to show a tag in the attribute syntax without specifying the parent tag. In this case use '.' to mean the default tag. e.g.:

. class=my-class id=my-id|text to emphasise with class

This shows as:

<H2 class="my-class" id="my-id">text to emphasise with class</H2>

if <H2> is the default tag at that level.

Curly brackets

There is an abbreviated way of showing a subnode with the default tag. The text is put in curly brackets

like {this}

. This is an abbreviated form of

like [.|this]

This is convenient for tables, e.g.

table|
	{{a}{b}{c}}
	{{1}{2}{3}}

will create:

<table>
	<tr><td>a</td><td>b</td><td>c</td></tr>
	<tr><td>1</td><td>2</td><td>3</td></tr>
</table>

You could also write this as:

table|{{a}{b}{c}}{{1}{2}{3}}

Escaping characters

Escape Sequences
CHAR	ESCAPE SEQUENCE
[	~[, [lb], [left-brace]
]	~], [rb], [right-brace]
{	~}, [right-curly]
{	~{, [left-curly]
\|	~\|, [pipe]
~	~~, [tilde]
SPACE at beginning of line	"~ ", [SPACE]
TAB at beginning of line	"~\t", [TAB]
QUOTE in attribute contents	~", [QUOTE]

Note chars do not need to be escaped if they are not in a position to be interpreted as special chars. e.g. quote marks only need to be escaped if they are in attribute values.

There are no escape sequences for dots (.) or equals (=), therefore these can not be used in identifiers (tags), and "=" can not be used in attribute values.

The following always need to be escaped if literal chars: [,],{,},|,~

Writing JOT files (HTML)

The default schema will produce HTML when used with jotxml2html.xsl.

If the first line is not indented it is used as the page title.

Lines indented by one tab are tagged <H1>, 2 tabs <H2> etc up to <H4>. After 6 indents text is shown as <p> only.

Some useful tags

comment

nodes tagged comment are suppressed in the HTML

ul ol list num

ul makes an unnumbered list. ol makes a numbered list.

list can have a subnode of num which can take values ol, ul, numbered, or empty. The default is unnumbered

case when (variant files)

Text can be shown only in some outputs of the XSL by using the tags "when" and "case", e.g.:

case when=web| Download [a r=url|here]

If the XSL file is processed with a parameter of 'choose' containing the text 'web', then the node will be output, otherwise it will not.

For example: saxonb-xslt -s:"$1.xml" -xsl:"jotxml2html.xsl" -o:"$filename.html" choose=web

a r

a makes an HTML a tag and r an HREF attribute. Example:

[a r=http://github.com/t-d-k/jot|Just and Only text]

l

l (lower case L) makes a link to a heading in the document (any text indented 4 tabs or less). The contents of the tag should be the same as the first 20 characters of the heading.

Example:

[l|Some useful tags]

h

h makes a link to an external url. The contents of the tag should be the same as the url after https://.

Example:

Go to [h|github.com/t-d-k/jot]

citation

This creates footnotes. Example:

Which is shown in Pew [citation link=true|http://www.pewresearch.org/url].

See jotxml2html.xsl.

table header row cell

Creates HTML tables, e.g.

table|
	header|{option}{meaning}  	{  {-o <filename>}{output file}                  }	{  {-s <filename>}{schema file, can be omitted}  }	{  {-k}{do not check schema}                     }

The default child of table is row, and the default child of row is cell

LEV

This is the default tag for plain text, the HTML tag produced depends on the indent level

Others

Most HTML tags and attributes can be produced by using the same string as a jot tag, e.g.

[p id=myid|some text]

. To add new ones, update both default.schema.jot and jotxml2html.xsl, see <i> and <class> as examples.

Jot2xml

Expects its input in UTF-8. Both Windows and Unix line endings are supported. The output is in UTF-8, using Unix line endings.

option	meaning
-o <filename>	output file
-s <filename>	schema file, can be omitted
-k	do not check schema

Writing schemas

Schemas are themselves jot files. Each top level node represents a tag, and the subnodes represent child tags allowed. A tag of 'default' means that is the default child tag, and text tagged 'comment' is ignored e.g.:

ol
	default|p
	comment|common to all tags
	id
	when

means that 'id', 'p' and 'when' are the only permitted child tags of ol', and the default is 'p'.

The schema must contain 'xml' as a node, which is the document as a whole. Nodes under this are top level tags (i.e. not indented)

The schema for schema files is:

xml
	default|tag
	comment
tag
	default|subtag
	comment
	default
default
	subtag
comment
	comment-text
comment| no child nodes allowed under sub tags
subtag
comment| no child nodes allowed under comment text
comment-text

However when parsing a schema, the schema of the schema is not checked
